External Cleaning Solution 1L MEK for EBS Handjet

Cleaning Procedure: Black MEK Based Ink

• Daily: The print nozzle on the face of the printer should be sprayed with this MEK External Cleaning Solution and dry the nozzle plate face with a microfiber cloth.

• Twice Weekly: Purge the unit by flushing the system using the MEK Cleaning Cartridge (EBS4A002KR)

How-To Purge:

• Power down the printer
• Remove the ink cartridge
• Before Installing a cleaning cartridge, ensure you have the proper cartridge or the printer will not accept it. Your cleaning cartridge should match the type of ink your printer is configured to print.
• Power on the printer and printer will begin to pressurize, wait for the printer to complete pressurization
• Please reference the following steps depending on the type of printer you are operating:

Purging steps for the EBS-250:

• In a well-ventilated area rapidly press the trigger three times, hold the trigger down on the third press.
• The unit will sound three beeps
• Point the unit towards a scrap piece of cardboard/hazmat container
• The unit will sound two beeps then fire all 16 nozzles at once
• Purge the unit for approximately 10-15 seconds, then release the trigger.
• Power down the unit and install the ink cartridge to prevent dust and contaminants from entering the unit.

Purging steps for the EBS-260:

• In a well-ventilated hold down the start button on the bottom right side of the touch screen on the printer.
• The unit will begin to pressurize and beep
• Point the unit towards a scrap piece of cardboard/hazmat container
• Pull the trigger and the unit will fire all 32 nozzles at once
• Purge the unit for approximately 10-15 seconds, then release the trigger and press stop.
• Power down the unit and install the ink cartridge to prevent dust and contaminants from entering the unit.

This product requires hazmat certification to ship and is nonrefundable unless the unopened product can be returned to Dasco.
